Supermaster Two Platen Series

Advanced Servo Hydraulic Injection Molding Machines

Time Tested

First launched in 2008 The SM Two Platen Servo Drive injection molding series has gone over relentless improvements of the past years and remains one of our flagship machine series.

Tried & Proven

Hundreds of presses from the SM700 up to SM6500 tons are currently running reliably for customers around the world in every industry.
They deliver high precision, high stability, high speed, and ultimate mold protection without any of the traditional compromises.

Clamping – from 700 to 6500 tons!

Major Advantages of SM-TP Machines

  • 1

    Incredible Speeds:

    Up to 700mm/s speed in Clamp open/close.
  • 2

    High Efficientcy Servo Motors:

    Reducing energy consumption up to 80%, bringing high precision and super low noise operation.
  • 3

    Unique Mix and Match Capability:

    You may select from 14 sizes of different clamping units and match it with 14 different injection units.
  • 4

    Speedy Setup:

    Fast die height and clamping setup technology. (Die height adjustment in only 20 seconds).
  • 5High Speed Clamping Pressure Build Up.
  • 6High Pressure Injection and Fast Speed Recovery.
  • 7Optional Ejector on the Fly.

Specs

Machine ModelUS TonsPlaten Size (in)Tie Rod Clearance (in)
Opening Stroke (in)Max daylight (in)Min-Max Mold Height (in)
PDF
SM700771.659.05×59.0540.15×40.1547.24-74.8090.5515.74-43.3Download
SM85093766.14×66.1446.06×46.0649.21-78.7496.4517.71-47.24Download
SM10501157.470.86×70.8650.39×50.3951.18-82.67102.3619.68-51.18Download
SM1250137876.77×74.854.33×50.3959.05-90.55110.2319.68-51.18Download
SM14501598.378.74×78.7457.87×53.9364.96-96.45118.1121.65-53.15Download
SM16501818.885.03×83.4661.81×57.8766.92-98.42122.0423.62-55.11Download
SM19002094.490.55×88.9765.74×61.0266.92-98.42125.9827.55-59.05Download
SM2200242594.98×90.5575.59×71.6570.86-98.42125.9827.55-62.99Download
SM26002866106.29×102.3675.98×68.1174.80-102.36149.631.49-66.92Download
SM30003307110.23×108.6679.52×71.6582.67-118.11153.5435.43-70.86Download
SM36003968.3118.11×114.1785.43×75.5986.61-125.98165.3539.37-78.74Download
SM45004960.4129.92×123.2295.67×82.6790.55-133.85177.1643.3-86.61Download
SM55006062.7139.76×132.67103.15×88.58102.36-149.6196.8547.24-94.48Download
SM65007165149.6×142.91108.66×94.48106.29-153.54204.7251.18-98.42Download
Specifications are subject to change without notice.
Model IDScrew L/D ratio L/DShot size (PS) OuncesScrew Stroke InchesScrew Rotation Speed RPMPDF
J20.3~2281~8915.74150Download
K20.2~2291~10917.71140Download
N19.6~22120~15219.68130Download
P20.2~22167~20021.65115Download
Q20.3~22217~25523.62110Download
A20.4~22276~32125.59100Download
R20.5~22345~39627.5695Download
B18.9~22464~63232.2880~95Download
C19.3~22740~96737.7969~83Download
D19.6~221108~140343.350~65Download
E19.8~221581~195348.8150~60Download
F20~222157~261053.9347~60Download
G20.2~222858~340159.0550Download
H223812.4464.9640Download
Specifications are subject to change without notice.

CBmold800

German engineering-Beckhoff Controls

Customized for the SM-TP series

Controls

  • 1

    BECKHOFF – Made in Germany:

    Powered by German engineering-Beckhoff controls and customized for the SM-TP machines.
  • 2

    User Friendly Touch-screen:

    15 inch multi touch screen display providing user friendly operation and comprehensive list of settings and options.
  • 3

    Intelligent Control System:

    Can-Bus based I/O creating the fastest response and reliability.
  • 4

    Flexibility:

    Isolated and expandable I/O for special operations/options/Automations.
  • 5

    Save your Data:

    Unlimited mold data saving using thumb drive.
  • 6

    Advanced Reports:

    Provides various reports for production, settings, alarm records and logs of operational settings.
  • 7

    Network ready:

    Ready to plug into a cloud-based service and participate in the IOT at the very fundamental level.

Injection

  • 1Injection pressure from 18000PSI up to 28000PSI provided by dual-parallel high pressure injection cylinders and shot size starting from 81oz up to 3812oz.
  • 2Injection unit Swivel for easy barrel and screw maintenance.
  • 3Linear bearing based injection unit to evenly distribute the stress of injection pressure for raising the machine repeatability and reliability.
  • 4High Torque fast speed hydraulic motor or E-drive for screw rotation.
  • 5Back pressure controlled by proportional or LDVT valves to provide the finest contrast in recovery.
Photo Gallery
CBmolc800 German engineering-Beckhoff Controls
Enlarged End-cap design to ease the maintenance of the screw tip assembly and nozzle.
Standard SPI/CE based electric safety features.
Beckhoff-Germany Can-Bus based controller featuring fully isolated I/O.
Latest technology of Servo system providing up to 80% energy saving, precision and low noise operation, including SPI/CE based layout and wiring.
Clamping system is being tested for multiple hours before delivery, using trial tool blocks.
Integrated Valve Gate and Hot Runner controls plus multiple programmable core pulling circuits.
SPI/SE based isolated I/O, components layout and wirings.
Simplified and practical locking mechanism design featuring long term operation without failure.
Touch less linear transducers featuring long term safe and precise operation.
Beckhoff controller a Multilanguage user-friendly controller featuring SPI and Metric measuring system and full range of settings and control capabilities.
SM-TP machines are manufactured with SPI mold mounting and ejector patterns and can be ordered with optional T-Slots, mounting holes or combination of both.
Ejector system design allows the set-up technician plenty of room and an ergonomic environment to work with the mold-mounted ejector rods.
Electric screw drive screw available. This feature increases the recovery speed and saves cycle time in manufacturing of products, as well as reducing energy consumption and decreasing noise level.
Chen Hsong manufactures more than 15,000 machines a year ranging from 80 up to 7,000 US tons.
The latest technology is used in the fast response gear pumps which ,in combination with the servo motor drive, brings precise, repeatable, and reliable performance.
SPI/CE based full coverage of the barrel and nozzle, brings a safer environment for the operators and set-up technicians.
Ergonomic and user friendly placement of controlling components brings the operator an experience of smooth control over the machine.
Operator friendly design allows accessibility, safety, and a clean working environment.
Two platen design brings larger range of die height, as well as daylight with up to 30% less footprint.
Chen Hsong Injection Molding Machine: SM1900-TP
Chen Hsong Injection Molding Machine: SM700-TP-SVP/2

Request a Quote

Choose your options:

    Electric screw drive screw for high speed and on-fly operations
    Integrated Hot runner system (control and hardware)
    Integrated valve gate (hydraulic/pneumatic) control and hardware
    Herzog shot-off nozzle
    Additional hydraulic core pullers or air blast up to 6 sets of each
    Gas assist injection for light weight productions
    Accumulated injection for thin wall productions


    Special Barrel and screw design for engineered and reinforced materials (with Glass Fiber, etc.)
    Special made machines for rigid UPVC production including widen safety doors and air cooled barrel heater bands.
    Special made machines for PET production with higher capacity of injection and recovery and 1:25 L/D ratio and reinforced ejection system.
    Local or long distance networking, monitoring capability and Industry 4.0 ready
    Automation ready
